| 比较 |
|---|
| 厂家型号 | 煤安型号 | 冲击频率 | 冲击能量 | 活塞（锤体） | 工作气压 | 耗气量 | 进气口尺寸 | 全长 | 噪音 | 重量 | 尖头凿刀 | 平头凿刀 | |
| bpm | J | 直径mm | 行程mm | MPa | m3/min | inch | mm | dB(A) | kg | model | model | ||
| CGQ-2 | JPCQS-2 | 3000 | ≥10 | 19 | 65 | 0.63 | 0.2 | 1/4 | 217 | ≤95 | 2 | CG1-10H | CG1-10HF |
| CGQ-6.5 | — | 2500 | ≥20 | 17.5 | 25.4 | 0.63 | 0.7 | 3/8 | 388 | ≤105 | 6.5 | CG2-17 | CG2-17F |
| CGQ-9 | JPCQS-9 | 1700 | ≥35 | 28.5 | 142 | 0.63 | 0.6 | 3/8 | 445 | ≤100 | 9 | CG2-15H | CG2-15HF |
| CGQ-13 | JPCQS-13 | 1700 | ≥43 | 35 | 102 | 0.63 | 0.9 | 1/2 | 482 | ≤118 | 13.5 | CG3-26 | CG3-26F |
| CGQ-20 | JPCQS-21 | 1000 | ≥55 | 40 | 165 | 0.63 | 1.2 | 3/4 | 565 | ≤120 | 20 | CG5-30 | CG5-30F |
| CGQ-28 | JPCQS-28 | 850 | ≥55 | 45 | 165 | 0.63 | 1.3 | 3/4 | 595 | ≤120 | 28 | CG6-35 | CG6-35F |
| CGQ-32 | JPCQS-33 | 800 | ≥65 | 45 | 200 | 0.63 | 1.5 | 3/4 | 672 | ≤125 | 32 | CG6-35 | CG6-35F |
| CGQ-40 | JPCQS-41 | 1080 | ≥100 | 63.5 | 120 | 0.63 | 3 | 3/4 | 686 | ≤128 | 40 | CG7-32H | CG7-32HF |
