| 比较 |
|---|
| 厂家型号 | 额定起重量 | 标准起重高度 | 提升高度范围 | 试验载荷 | 满载时手拉力 | 起重链条挂数 | 起重链条直径 | 重量 |
| T | m | M | KN | N | 根 | mm | kg | |
| DHM-0.5 | 0.5 | 3 | 0-15 | 6.1 | 249 | 1 | 5*15 | 9 |
| DHM-1 | 1 | 3 | 0-15 | 12.3 | 284 | 1 | 6*18 | 12 |
| DHM-2 | 2 | 3 | 0-15 | 24.5 | 343 | 1 | 8*24 | 20 |
| DHM-3 | 3 | 3 | 0-15 | 36.8 | 343 | 2 | 7*21 | 27 |
| DHM-5 | 5 | 3 | 0-15 | 61.1 | 413 | 2 | 10*30 | 40 |
| DHM-10 | 10 | 3 | 0-15 | 122.5 | 415 | 4 | 10*30 | 80 |
| DHM-15 | 15 | 3 | 0-15 | 183.8 | 420 | 6 | 10*30 | 140 |
| DHM-20 | 20 | 3 | 0-15 | 245 | 425*2 | 8 | 10*30 | 160 |
| DHM-30 | 30 | 3 | 0-15 | 367.5 | 425*2 | 12 | 10*30 | 350 |
