| 比较 |
|---|
| 型 号 | 扭矩范围 | 方驱 | 工作压力 | 重量 | L1 | L2 | L3 | H1 | H2 | H3 | H4 | R1 | R2 |
| N.m | inch | Mpa | kg | mm | mm | mm | mm | mm | mm | mm | mm | mm | |
| YWG-1100 | 110-1100 | 3/4" | 60-70 | 1.6 | 104 | 151 | 50 | 42 | 63 | 76 | 106 | 20 | 82 |
| YWG-1800 | 180-1800 | 3/4" | 60-70 | 2.7 | 138 | 194 | 63 | 50 | 73 | 96 | 140 | 26 | 107 |
| YWG-3000 | 300-3000 | 1" | 60-70 | 3.6 | 149 | 213 | 70 | 60 | 87 | 111 | 157 | 29 | 112 |
| YWG-4500 | 450-4500 | 1" | 60-70 | 4.8 | 168 | 244 | 79 | 70 | 99 | 125 | 165 | 34 | 132 |
| YWG-7500 | 750-7500 | 1-1/2" | 60-70 | 8.8 | 207 | 296 | 99 | 80 | 124 | 152 | 193 | 40 | 162 |
| YWG-10000 | 1000-10000 | 1-1/2" | 60-70 | 12 | 226 | 326 | 110 | 90 | 133 | 170 | 211 | 46 | 178 |
| YWG-15000 | 1500-15000 | 1-1/2" | 60-70 | 14.5 | 250 | 366 | 120 | 100 | 143 | 186 | 227 | 50 | 199 |
| YWG-20000 | 2000-20000 | 2-1/2" | 60-70 | 19 | 281 | 402 | 132 | 112 | 165 | 208 | 249 | 56 | 218 |
| YWG-26000 | 2600-26000 | 2-1/2" | 60-70 | 25 | 304 | 442 | 146 | 120 | 183 | 226 | 267 | 60 | 240 |
| YWG-35000 | 3500-35000 | 2-1/2" | 60-70 | 37.5 | 331 | 483 | 158 | 138 | 202 | 250 | 291 | 66 | 260 |
| YWG-50000 | 5000-50000 | 2-1/2" | 60-70 | 42 | 390 | 558 | 177 | 150 | 219 | 282 | 323 | 77 | 298 |
| YWG-60000 | 7000-70000 | 3" | 60-70 | 58.0 | 418 | 596 | 195 | 166 | 236 | 300 | 366 | 82 | 325 |
