| 比较 |
|---|
| 型 号 | 预置扭矩范围 | 分度值 | 总长 | 有效力臂 | 方头尺寸 | 重量 |
| N.m | N.m | mm | mm | inch | kg | |
| ZNM-5 | 1-5 | 0.05 | 186 | 120 | 1/4" | 0.20 |
| ZNM-10 | 2-10 | 0.1 | 203 | 140 | 3/8" | 0.25 |
| ZNM-25 | 5-25 | 0.25 | 257 | 190 | 3/8" | 0.45 |
| ZNM-30 | 5-30 | 0.25 | 255 | 190 | 3/8" | 0.45 |
| ZNM-50 | 10-50 | 0.5 | 307 | 240 | 3/8" | 0.55 |
| ZNM-60 | 10-60 | 0.5 | 307 | 240 | 3/8" | 0.55 |
| ZNM-100 | 20-100 | 1 | 420 | 350 | 1/2" | 0.90 |
| ZNM-200 | 40-200 | 1 | 525 | 430 | 1/2" | 1.50 |
| ZNM-300 | 60-300 | 1.5 | 680 | 575 | 1/2" | 2.85 |
| ZNM-400 | 100-400 | 2 | 780 | 655 | 3/4" | 3.15 |
| ZNM-500 | 125-500 | 2.5 | 890 | 755 | 3/4" | 3.50 |
| ZNM-600 | 150-600 | 3 | 890 | 990 | 3/4" | 3.50 |
| ZNM-680 | 200-680 | 4 | 1098 | 990 | 3/4" | 6.50 |
| ZNM-800 | 200-800 | 4 | 1098 | 990 | 3/4" | 6.50 |
| ZNM-1000 | 200-1000 | 5 | 1295 | 1180 | 1" | 7.80 |
| ZNM-1200 | 400-1200 | 5 | 1300 | 1180 | 1" | 8.00 |
| ZNM-1500 | 450-1500 | 5 | 1300 | 1180 | 1" | 8.50 |
| ZNM-2000 | 720-2000 | 16 | 1300 | 1180 | 1" | 8.50 |
| ZNM-2500 | 900-2500 | 10 | 1400 | 1200 | 1" | 14.45 |
| ZNM-3000 | 1200-3000 | 30 | 1300 | 1200 | 1" | 14.80 |
| ZNM-4000 | 1600-4000 | 20 | 1500 | 1368 | 1-1/2" | 25.00 |
| ZNM-5000 | 2200-5000 | 40.00 | 1605 | 1475 | 1-1/2" | 26.50 |
| ZNM-6000 | 2800-6000 | 40.00 | 1605 | 1475 | 1-1/2" | 26.50 |
