| 比较 |
|---|
| 型 号 | 预置扭矩范围 | 分度值 | 总长 | 有效力臂 | 方榫公称尺寸 | 重量 |
| N.m | N.m | mm | mm | inch | kg | |
| ZNM-10S | 2-10 | 0.01 | 365 | 290 | 1/4" | 0.70 |
| ZNM-20S | 4-20 | 0.01 | 372 | 290 | 1/4" | 0.70 |
| ZNM-50S | 10-50 | 0.01 | 372 | 290 | 3/8" | 0.75 |
| ZNM-100S | 20-100 | 0.10 | 416 | 340 | 1/2" | 1.00 |
| ZNM-200S | 40-200 | 0.10 | 520 | 440 | 1/2" | 1.45 |
| ZNM-300S | 60-300 | 0.10 | 595 | 515 | 3/4" | 1.90 |
| ZNM-500S | 100-500 | 0.10 | 750 | 665 | 3/4" | 2.20 |
| ZNM-800S | 160-800 | 0.10 | 935 | 855 | 3/4" | 5.00 |
| ZNM-1000S | 200-1000 | 1.00 | 935 | 855 | 1" | 5.00 |
| ZNM-1500S | 300-1500 | 1.00 | 1280 | 1165 | 1" | 6.90 |
| ZNM-2000S | 400-2000 | 1.00 | 1280 | 1165 | 1" | 6.90 |
| ZNM-3000S | 600-3000 | 1.00 | 1480 | 1385 | 1" | 12.50 |
| ZNM-5000S | 1000-5000 | 1.00 | 1820 | 1680 | 1-1/2" | 26.20 |
