| 比较 |
|---|
| 厂家型号 | 工作扭矩 | 扭矩范围 | 方头尺寸 | 空载转速 | 外径 | 总长度 | 进气口 | 重量 |
| N.m | N.m | inch | rpm | mm | mm | inch | kg | |
| ZNQ-500 | 500 | 100-500 | 3/4" | 50 | 60 | 170 | 1/4" | 4 |
| ZNQ-1000 | 1000 | 150-1000 | 3/4" | 28 | 74 | 250 | 1/4" | 5 |
| ZNQ-1500 | 1500 | 200-1500 | 1" | 21 | 76 | 260 | 1/4" | 5.2 |
| ZNQ-2000 | 2000 | 300-2000 | 1" | 15 | 76 | 260 | 1/4" | 5.5 |
| ZNQ-3000 | 3000 | 500-3000 | 1" | 10 | 93 | 340 | 1/4" | 7.5 |
| ZNQ-4000 | 4000 | 700-4000 | 1-1/2" | 7 | 97 | 340 | 1/4" | 9.5 |
| ZNQ-6000 | 6000 | 1000-6000 | 1-1/2" | 5 | 105 | 380 | 1/4" | 14 |
| ZNQ-8000 | 8000 | 2000-8000 | 1-1/2" | 4 | 113 | 380 | 1/4" | 18 |
| ZNQ-10000 | 10000 | 2000-10000 | 1-1/2" | 2.5 | 120 | 390 | 1/4" | 20 |
| ZNQ-12000 | 12000 | 3500-12000 | 1-1/2" | 1.8 | 126 | 395 | 1/4" | 21 |
